1.Switch rating: Ui:500V，Ith:10A
2.Mechanical life: ≥1,000,000 cycles
3.Electrical life: ≥50,000 cycles
4.Contact resistance: ≤50mΩ
5.Insulation resistance: ≥100MΩ(500VDC)
6.Dielectric strength: 3,000V，RMS 50Hz，1min
7.Operation temperature: -25 ℃~55℃ (+no freezing)
8.Operation pressure: About 10N(1NO1NC)，about 17N(2NO2NC)
9.Operation travel: About 3.8 mm(push button)
10.Front panel protection degree: IP40(IP65 made to order )
MATERIAL:
1.Contact: Silver alloy
2.Head: Aluminium alloy
3.Body: PA
4.Base: PC
Customization
1.Mechanical Customization: Dimensions, Button Design, Mounting Structure, Tail Wiring + Connectors
2.Electrical Configuration： Momentary, Latching, Voltage Options, SPST/SPDT/DPST/DPDT
3.LED & Appearance： Laser Engraving, Illuminated Patterns, Button Cap / Housing / LED Colors, Head Shape, Surface Treatment， Contact Materials
4.Protection Options：IP65/IP67/IP68，Stainless Steel, Anti-Vandal, High/Low Temperature Materials, Oil-Resistant Materials
Customization options vary by product model. Please contact our sales team to confirm available configurations.
