1.Switch rating: 2A/36VDC
2.Mechanical life: ≥500,000 cycles
3.Electrical life: ≥ 200,000 cycles
4.Contact resistance: ≤50mΩ
5.Insulation resistance: ≥100MΩ(500VDC)
6.Dielectric strength: 1,500V，RMS 50Hz，1min
7.Operation temperature: -25 ℃~55℃ (+no freezing)
8.Operation pressure: About 1.5N
9.Operation travel: About 1.5mm
10.Torque: About 0.3Nm Max.applied to nut
11.Front panel protection degree: IP65 (IP67 made to order),IK07
12.Terminal type: Pin terminal (2x0.5mm)
MATERIAL:
1.Contact: Silver alloy
2.Button: Stainless steel
3.Body: Stainless steel
4.Base: PA
Customization
ONPOW undertakes a variety of custom needs for push-button development. Confirm whether packaging, marking or documentation OEM/ODM applies to GQ12-AH-10E/S in the quotation.
Minimum order quantity, lead time and trade terms are not published here; confirm them with sales at sales@onpow.com.
